Ecoflex 10

Low loss 50 Ohm coaxial cable assembly with

BNC male connector clamp to SMA female bulkhead (nickel plated) Crimp

Cable length 1m

Application examples:
Antenna cables, instrumentation cables, patch cables, test leads,
Connecting cables, extension cords, u.v.m.
Frequency range up to 6 GHz

Amateur radio (AFU)
Data acquisition via (RFID)
Mobile (GSM, LTE, MIMO and UMTS)
Navigation (GPS)
Telephony (DECT)
Wireless network technology (WLAN)
General Electronics DC up to 6 GHz

Attenuation values for Ecoflex 10 based on 1m cable length:

  800 MHz ~ 0.12 dB
1000 MHz ~ 0.14 dB
1300 MHz ~ 0.17 dB
1500 MHz ~ 0.18 dB
1800 MHz ~ 0.2dB
2000 MHz ~ 0.21 dB
2400 MHz ~ 0,24dB
2600 MHz ~ 0.25 dB
5600 MHz ~ 0.39 dB

Please note:
Due to the conversion to 1m cable length may cause discrepancies
come from +/- 1% of the specified attenuation values!
Please see if in doubt always to the data sheet for Ecoflex 10.
